LN Kart Four Kart Chassis & Senior MAX EVO Engine

Original Tony Kart (OTK) LN Kart Four Direct Drive chassis with Senior MAX EVO complete engine kit. Everything needed to get on the grid and win!

CHASSIS-

• BARE FRAME - CIK-FIA homologated chrome steel (D.30), specifically studied for direct drive categories, adjustable in height both front and rear.
• AXLE – 50 x 1030mm Type N
• TORSION BARS - Provided front flat, rear optional
• COMPONENTS - Magnesium
• CAMBER AND CASTER ADJUSTMENT - With d.10mm incorporated uniball eccentric washers
• STUB AXLES - HST with d.25mm pin
• STEERING WHEEL - 4 spokes with new HGS covering
• BRAKE SYSTEM - Only rear BSD with 180x13mm rear disc
• PEDALS - Adjustable footrest and pedals in aluminium
• BODYWORKS - M10 bodyworks and Blue front spoiler M7 complete with stickers kit and plastic rear bumper (CIK-FIA homol.)
• SEAT - In fiberglass with flat bottom (sizes- junior, 1, 2, 3, 4)
• WHEELS SET - MXJ 130-212
• CHAIN GUARD - Integral complete with one-piece supports
• FLOOR-PLATE - Integral
• EXHAUST SUPPORTS - Provided with silencer cradles and brackets to suit Rotax
• ENGINE MOUNT - Provided with brackets for Rotax engine

HOMOLOGATION CIK/FIA 012/CH/12

ENGINE-

MAXIMUM PERFORMANCE- 22 kW / 30 hp at 11,500 rpm
MAXIMUM TORQUE- 21 Nm at 9,000 rpm
WEIGHT- Bare engine: 12.0 kg / 26.5 lbs, with complete power pack: 23.1 kg / 51.0 lbs
SPECIAL FEATURES- Cylinder with electronically controlled exhaust valve
POWER PACK- Intake silencer, carburetor, fuel pump, engine, exhaust system, radiator, battery box incl. cover, cable harness, Off/On/Start switch, relay
CHASSIS COMPATIBILITY- Wheel base: 1,040 mm

Complete engines are supplied with:
• Intake silencer with air cleaner
• Dell´Orto carburetor VHSB 34 XS
• Pneumatic fuel pump with  bracket and fuel hoses
• Exhaust system with silencer
• Radiator with cap
• Battery box with start button, relay and cable harness
• NGK spark plug
• Battery charger & ROW connector

Chassis & engine bundle includes a battery, rear sproket & chain size of your choice.

TYRES NOT INCLUDED, MOJO AVAILABLE HERE.
